Rainbow Robotics collaborative robots are classified into N, E, and U versions depending on the product generation.

· 1st generation: N version
· 2nd generation: E version
· 3rd generation: U version

The versions can also be identified by their appearance.

· N version: Features translucent plastic joint covers. (Three Phillips-head cover bolts)
· E version: Features aluminum joint covers. (Four Phillips-head cover bolts)
· U version: Features aluminum joint covers with thicker joint bands. (Four star-drive cover bolts)

No. N, E, and U versions are not compatible with one another.

Each version has a different main-cable pinout and hardware configuration between the robot and the control box. Therefore, robots and control boxes from different versions cannot be used together. For example:

· N-version control box ↔ N-version robot
· E-version control box ↔ E-version robot
· U-version control box ↔ U-version robot

The robot and control box must always be of the same version.

In addition, for high-payload models such as the RB20 and RB30, use a control box equipped with an SMPS of the appropriate capacity for the robot’s power consumption. Using a control box not recommended for the applicable model may prevent normal operation.

No. iOS devices, including iPhones and iPads, are not currently supported.

Rainbow Robotics collaborative robots can be used with Android smartphones and tablets, as well as Windows and Linux environments.

No. N, E, and U versions are not compatible with one another.
Because each version has a different main-cable pinout and hardware configuration between the robot and control box, robots and control boxes from different versions cannot be used together. For example:
· N-version control box ↔ N-version robot
· E-version control box ↔ E-version robot
· U-version control box ↔ U-version robot
The robot and control box must always be of the same version.
For high-payload models such as the RB20 and RB30, use a control box equipped with an SMPS of the appropriate capacity for the robot’s power consumption. Failure to use the recommended control box for each model may prevent normal operation.

In the RB UI, go to Set-up → Log/Utility. Select [Import], then [Load] to view logs.

If the RB UI is connected to the internet, you can also use the [Mail] icon to send logs to Rainbow Robotics Technical Support at support@rainbow-robotics.com.

For detailed instructions on viewing and sending logs, please refer to the Collaborative Robot Technical Support Web Manual.

To connect a tablet to the control box, use an A-to-C cable. (Control box: USB-A port; tablet: USB-C port.)

To connect a laptop to the control box, use an Ethernet (LAN) cable rather than an A-to-C cable. Configure the control box and laptop to use the same network range (IP subnet), then connect through TCP/IP communication.

Yes. Rainbow Robotics provides Python and C++ examples and SDKs through GitHub. Please refer to the example files when developing your application.

Before contacting Technical Support, please check the displayed error code and the robot arm’s serial number.

Providing this information will help us provide support more quickly.

You can find detailed information about error codes by using the search function in the Collaborative Robot Technical Support Web Manual.

Connect the RB UI to the control box, then go to Set-up > System to perform the software update.
